PE1358A
Sami MultiNode DDCS is a protocol converter designed to connect up to eight
different Selma/Sami/Sele to ABB ModuleBus (DDCS+). The unit is enclosed in a metal
box with connection terminal for Power supply and Sami/Sele connection.
Connector type HP Versatile link for ABB ModuleBus connection.
The ModulBus communication is handled by a 80C32 microprocessor and the eight
Sami/Sele communication links is handled by a Hitachi H8/532 microprocessor. The
two microprocessors are communicating thru a dual port memory.
